Searchline Excel™ Plus

Open Path Infrared Gas Detector is an example.For a long-range, infrared gas detection that is safe for outdoor use. For detecting flammable gases at long distances up to 200m, the Searchline ExcelTM Plus is a top-tier infrared gas detector. With a fail-safe optical design, the Excel Plus is built to withstand the toughest outdoor conditions with minimal false alarm risk and dependable reliability. Enquire Now

Product Highlights




    Features

    • Extended Range. Detects inflammable substances up to 200m away from the surface.’
    • Environmental Resistance. Constructed to endure rainy, snowy weather, mist, scorching heat, and sandstorm conditions.
    • False Alarm Immunity. Patented optical design reduces weather-related nuisance alarms.
    • Modular Installation. Separate transmitter and receiver to allow for flexibility.
    • Auto-Alignment. The intelligent alignment system optimizes performance during setup and maintenance..

    Specifications

    Feature Details
    Detection Hydrocarbons (IR absorption)
    Range 5–200 meters
    Output 4–20 mA + HART / Modbus
    Response Time <1 second
    Operating Temp -40°C to +65°C
    Protection IP66/IP67, SIL2 certified
    Certification ATEX, IECEx, UL, CSA
    Power 18–32 VDC



    Applications

    • Oil Refineries and Offshore Platforms
    • LNG Terminals and Storage Yards
    • Chemical Tank Farms
    • Industrial Fence Line Monitoring
