Features
- High-Accuracy Infrared CO₂ Measurement
Logs 0–10% vol (default); up to 30% vol configurable.
- Patented 4-Beam Optical Design
No drift, high dirt, fog, and beam block resistance.
- Ultra-Fast Response
Reaction time <1s in “high-speed” mode with configurable thresholds.
- Tough Stainless Steel Construction
SS316L explosion-proof housing with IP66/IP67, NEMA 4X rating.
- Configurable Output Signals
4-20 mA with HART®, beam block, fault, and maintenance signals.
15-year expected service life with low maintenance.
Specifications
Specification Details
Service Target GasCarbon Dioxide (CO₂)
Detection Range 0–2,000 ppm to 30% vol (configurable)
Response Time (T90)<4s (standard), <1s (high-speed)
Signal Output 4–20 mA + HART®, adjustable alarms (1.2–3 mA)
Temperature Range -40°C to +77°C (operation)
Enclosure SS316L, IP66 / IP67, M25 or ¾” NPT threads
Weight 2.2 kg
Power Consumption 5.6W (typical), 13–30 VDC
SIL Rating SIL 2 certified (TÜV) in accordance with EN 61508
Certifications ATEX, IECEx, UL, CSA, CE
Approvals Zone 1 & 2 (gas/dust), Class I/II Div 1 (US/Canada)
________________________________________
Applications
- Food and beverage CO₂ processing
- Wastewater and fermentation plants
- Oil & gas platforms and refineries
- LNG and gas storage terminals
- Clean-in-place (CIP) systems in pharma and F&B
