Specifications
| Specification |
Details |
| Gases Detected |
1 to 7 (simultaneous) |
| Dimensions |
179 x 77 x 42 mm |
| Weight |
495–550 g (based on config) |
| Operating Modes |
Diffusion / Pump (up to 45 m hose length) |
| Display |
High-contrast color display with zoom |
| Alarms |
LED (Red/Yellow/Green), 100 dB acoustic, vibration |
| Operating Temperature |
-20 °C to +50 °C |
| Ingress Protection |
IP68 |
| Battery Type |
Lithium-ion, inductive charging |
| Battery Life (Typical) |
Up to 120 hours (EC only), ~16-24 hrs with PID/IR/CatEx |
| Charging Time |
Approx. 4 hours |
| Data Storage |
24 MB (~400 hours @ full config) |
| Certifications |
ATEX, IECEx, cCSAus, ANZEx, EN 60079-29-1, EN 45544, etc. |
| Marine Approval |
DNV GL |
| Warranty |
3 years on device |
⚙️ Sensor Compatibility
- PID: PID LC ppb, PID HC (Isobutene, Benzene)
- IR: IR Ex, IR CO₂, Dual IR Ex/CO₂ ES & HC
- Catalytic Bead: CatEx 125 PR, CatEx PR Gas, CatEx H₂
- Electrochemical: O₂, CO, H₂S, NO₂, SO₂, NH₃, PH₃, HCN, Cl₂, COCl₂, VOCs, and more
🛠️ Compatible Accessories
- Probes: Telescopic probes, float probes, GP600 probe
- Hoses: FKM hoses (5 m to 45 m)
- Charging Options: Single/Multiple charging cradles, vehicle chargers, inductive bases
- Pump Components: Nonane adapter, dust/water filters
- PID Add-ons: Pre-tubes (benzene, humidity), cleaning sets
- Carrying Gear: Shoulder strap, transport bag, rubber boot, leather case
- Calibration: Dräger X-dock station, calibration adapters
- Software: Dräger CC Vision, GasVision
📌 Applications
- Confined space entry & clearance testing
- Oil & gas and petrochemical site monitoring
- HazMat, leak detection, and decontamination zones
- Fire brigade rescue operations
- Pharmaceutical, wastewater, and utility plant safety
