Specifications
| Parameter |
Details |
| Target Gases |
Oxygen (O₂), Hydrogen Sulfide (H₂S), Carbon Monoxide (CO) |
| Sensor Technology |
Electrochemical (O₂, H₂S, CO) |
| Battery Runtime |
Minimum 18 hours |
| Charging Time |
4 to 6 hours |
| Display |
LCD with real-time gas concentrations |
| Alarms |
Audible (95 dB), visual (LED), and vibrating |
| Operating Temperature |
-20°C to +50°C (-4°F to +122°F) |
| Humidity Range |
0% – 95% RH (non-condensing) |
| Ingress Protection |
IP68 (dustproof and waterproof to 1.5m for 45 min) |
| Dimensions |
11.3 x 6.0 x 3.2 cm (4.4 x 2.4 x 1.3 in) |
| Weight |
179 g (6.3 oz) |
| Sensor Life – O₂ |
5 years (X3 model) |
| Certifications |
ATEX, IECEx, CSA, CE, USA & Canada UL approvals |
⚙️ Sensor/Component Breakdown
| Sensor Type |
Gas Detected |
Typical Range |
Resolution |
| O₂ |
Oxygen |
0 – 30.0% vol |
0.1% vol |
| H₂S |
Hydrogen Sulfide |
0 – 100 ppm |
1 ppm |
| CO |
Carbon Monoxide |
0 – 500 ppm |
1 ppm |
🧪 Accessories & Add-ons
- MicroDock II Docking & Calibration System
- Multi-unit Charging Cradle
- Carrying Holster & Clips
- Calibration Gas Cylinders
- Sampling Pump (manual or motorized)
📌 Applications
- Confined space entry & worker safety
- Oil & gas refineries and offshore platforms
- Petrochemical and manufacturing plants
- Construction & utility maintenance sites
- Wastewater treatment facilities
- Mining and tunnel operations
