BW Clip Series 3 Year Real Time

Honeywell BW Clip Series – 3-Year Real-Time gas detector is the worker safety enhancer, bringing together some long storage life and instantaneous gas readings. This device is meant to remain operative for three years without intervention; however, the current one comes with a display for incorporating the concentration of gas, event logging features, and docking interface with IntelliDoX and MicroDock II systems to achieve the highest operating performance and regulatory compliance.Enquire Now

Product Highlights




    Features

    • 3-Year Maintenance-Free Design – No calibration, battery or sensor replacement
    • Real-Time Gas Concentration Display – View actual gas levels for immediate situational awareness
    • Data Logging of Events – Stores up to 35 gas exposure events
    • Single-Gas Monitoring – Available for H₂S, CO, O₂, and SO₂
    • Advanced Alarm System – Visual, audible, and vibration alerts
    • Docking Compatibility – Fully supports IntelliDoX and MicroDock II
    • End-of-Life Notification – Alerts users 30 days before expiry
    • Rugged Build – IP66/67 housing and compact form factor

    Specifications

    Specification Details
    Device Life 3 years
    Display Real-time gas concentration display
    Sensor Options H₂S, CO, O₂, SO₂
    Event Logging Up to 35 events
    Operating Temperature -40°C to +50°C
    Ingress Protection IP66/67
    Weight 92 g
    Dimensions 87 x 50 x 28 mm
    Alarms Audible, LED visual, vibration
    Battery Non-replaceable lithium battery
    Certifications ATEX, IECEx, CE, CSA
    Compatibility IntelliDoX, MicroDock II

    ✅ Applications

    • Industrial gas leak detection
    • Offshore drilling and refinery operations
    • Confined space safety assurance
    • Emergency and disaster response teams
    • Utility and water plant inspections



    Certifications & Compliance

    • ATEX, IECEx certified
    • CE marked for EU market
    • CSA certified for North America
