Features
- Dual detection of O₂, CO, H₂S, and CH₄ (LEL)
- dual sensor CO/H₂S in a single unit
- Li-ion battery with two model choices:
-Type: up to 60 days runtime (IR sensor)
-Type: up to 25 hours runtime (Pellistor sensor)
- small size, light weight (only 240 g) and wear comfort
- full function self-test on start-up: sensors, battery, circuitry
- event log memory for 30 bump tests/calibration records
- tInuitive backlight LCD with battery low indicator
- tATEX, IECEx, CSA, UL, INMETRO, and PESO approved
Specifications
Parameter Specification.
- Among the detected gases are O2 (O2), CO (carbon), H2S (hydrogen), and CH4 (methane).
- Electrochemical (O2, CO, H2S), IR, or CH4) are the two types of sensors used.
- The sensor is also available as a Pellistor Sensor.
- Detection Method Diffusion.
- Display a LCD screen with backlight illumination and numerical gas figures.
- Detection systems with vibration, red LED, and 90 dB audible alarms (10 cm).
- Rechargeable 2,000 mAh Li-ion battery.
- The N-Type IR battery can last for 60 days, while the P- Type Pellistor battery has a longer lifespan of 25 hours.
- Charging Time 4–6 hours.
- Prior to shutdown, there will be Low Battery Alarms that last for 20 / 10 /20 minutes.
- Operating Temperature −20°C to +50°C.
- The range of operating humidity for non-condensed air is 5% to 95%.
- With the IP67 rating, you can expect to find waterproof and dustproof protection.
- It measures 61 x 43,114 inches.
- Weight 240 g.
- 30 records of data gathered through various methods including alarms, bump tests and calibrations were recorded.
- Warranty 2 years.
⚙️ Sensor Ranges & Alarm Thresholds
| Gas |
Measuring Range |
Low Alarm |
High Alarm |
| O₂ |
0–30% vol |
19% |
23% |
| CO |
0–500 ppm |
30 ppm |
60 ppm |
| H₂S |
0–100 ppm |
10 ppm |
20 ppm |
| CH₄ (LEL) |
0–100% LEL |
10% LEL |
30% LEL |
🧪 Accessories & Add-ons
- MGT Docking Station (Single or Multi-Cradle)
- IR Link for configuration and data download
- USB-C Charging Cable and Adaptor
- External Sampling Pump with 5 m or 10 m probe
- Filter Adapter & Replacement Filter Kit
- Vehicle Power Adaptor
- Carrying case and belt clip
📌 Applications
- Confined space entry and air quality assessment
- Oil & gas drilling and refining
- Mining, chemical, and metal industries
- Wastewater treatment plants
- Emergency rescue and firefighting
- Industrial manufacturing and inspection
