Specifications

Feature                                     Specification

Internal Width                       60.5 ±1 mm (Sizes 1, 3, 5, 7) / 120.5 ±1 mm (Sizes 2, 4, 6, 8)

Depth                                        60 mm (Standard) / 120 mm (Extended)

Material Options                  Steel, Stainless Steel, Aluminum

EMC Shielding                     >100 dB (10 kHz – 30 MHz), >60 dB (30 MHz – 600 MHz), >50 dB (600 MHz – 2 GHz)

Installation Type                  Welded into pre-cut hole in deck or bulkhead

Frame Sizes                          1–8

Grounding/Bonding          Compatible with standard presswedge or endpacking

__________________________________

⚙️ System Components

• E-Standard Block: Copper sheet for EMC, EMP, and ESD protection
• E-AddBlock: EMC and grounding capability adjustable cable size blocks
• E-SpareBlock: EMC and grounding integrity space filler blocks
• E-PTG Presswedge: Compression block improving seal and EMC performance
• E-STG Endpacking: Seals frame between compression plate and frame top
• Stayplate: Gives stability between block rows
• Blanking Plate: Seals frame prior to block mounting; IP65/66 ingress protection
• Lubricant: Makes easy installation of Lycron components
• Installation Tools: L/S Packing Tool, Endpacking Puller, Quick Release Spanner, Cable Separator, Spacer Tool, Block Selector, Tweezers, EMC Marking Template

________________________________________

Accessories & Add-ons

• E-ALF Cabinet Seal: Easy, toolless installation
• CCM – Casting Module: Provides casting usage
• EMC Marking Template: Provides earth contact for all cables
• Welding Clamp: Provides secure welding for installation

________________________________________

Applications

• Marine & Offshore: Submarines, ships, vessels that need reliable sealing
• Land-Based: Industrial and infrastructure buildings that need EMC cable/pipe transits
• Industrial: Grounding, bonding, and fire safety control uses
